NTPsec

ntp2.sebi.org

Report generated: Thu Dec 25 08:53:01 2025 UTC
Start Time: Wed Dec 24 08:53:01 2025 UTC
End Time: Thu Dec 25 08:53:01 2025 UTC
Report Period: 1.0 days

Top   Daily Stats   Weekly Stats

Local Clock Time/Frequency Offsets

local offset plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Time Offset -1.125 -1.125 -0.964 -0.071 0.662 0.805 0.805 1.626 1.930 0.516 -0.053 ms -4.887 11.82
Local Clock Frequency Offset -6.775 -6.775 -6.745 -6.432 -6.185 -6.169 -6.169 0.560 0.606 0.156 -6.426 ppm -7.561e+04 3.201e+06

The time and frequency offsets between the ntpd calculated time and the local system clock. Showing frequency offset (red, in parts per million, scale on right) and the time offset (blue, in μs, scale on left). Quick changes in time offset will lead to larger frequency offsets.

These are fields 3 (time) and 4 (frequency) from the loopstats log file.



Local RMS Time Jitter

local jitter plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Time Jitter 132.474 132.474 146.307 180.499 256.654 275.179 275.179 110.347 142.705 32.664 190.077 µs 127.1 696.4

The RMS Jitter of the local clock offset. In other words, how fast the local clock offset is changing.

Lower is better. An ideal system would be a horizontal line at 0μs.

RMS jitter is field 5 in the loopstats log file.



Local RMS Frequency Jitter

local stability plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Frequency Jitter 14.686 14.686 17.829 36.825 51.337 61.844 61.844 33.508 47.158 10.538 36.103 ppb 21.51 72.04

The RMS Frequency Jitter (aka wander) of the local clock's frequency. In other words, how fast the local clock changes frequency.

Lower is better. An ideal clock would be a horizontal line at 0ppm.

RMS Frequency Jitter is field 6 in the loopstats log file.



Local Clock Time Offset Histogram

local offset histogram plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Offset -1.125 -1.125 -0.964 -0.071 0.662 0.805 0.805 1.626 1.930 0.516 -0.053 ms -4.887 11.82

The clock offsets of the local clock as a histogram.

The Local Clock Offset is field 3 from the loopstats log file.



Server Offsets

peer offsets plot

The offset of all refclocks and servers. This can be useful to see if offset changes are happening in a single clock or all clocks together.

Clock Offset is field 5 in the peerstats log file.



Server Offset 131.188.3.221

peer offset 131.188.3.221 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 131.188.3.221 -1.130 -1.130 -0.969 -0.035 0.651 0.720 0.720 1.620 1.850 0.492 -0.033 ms -4.663 11.26

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 185.131.196.23

peer offset 185.131.196.23 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 185.131.196.23 -1.032 -1.032 -0.896 0.091 0.727 0.848 0.848 1.624 1.880 0.489 0.086 ms -3.461 8.142

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 192.171.1.150

peer offset 192.171.1.150 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 192.171.1.150 -10.615 -10.615 -0.881 0.171 0.807 0.853 0.853 1.688 11.468 1.480 -0.063 ms -10.47 78.14

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 193.79.237.14

peer offset 193.79.237.14 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 193.79.237.14 -1.580 -1.580 -1.447 -0.452 0.183 0.244 0.244 1.630 1.824 0.475 -0.462 ms -13.95 43.49

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 2001:628:2030:dcf1::ac0 (ts1.aco.net)

peer offset 2001:628:2030:dcf1::ac0 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 2001:628:2030:dcf1::ac0 (ts1.aco.net) -0.673 -0.673 -0.355 0.779 2.141 5.642 5.642 2.496 6.315 0.981 0.873 ms 2.069 11.38

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 2001:638:a000:1123:123::1 (ntp0.rrze.ipv6.uni-erlangen.de)

peer offset 2001:638:a000:1123:123::1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 2001:638:a000:1123:123::1 (ntp0.rrze.ipv6.uni-erlangen.de) -1.223 -1.223 -1.051 -0.082 0.577 0.612 0.612 1.629 1.835 0.491 -0.071 ms -5.398 13.99

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 2a01:4f8:0:a112::2:2 (ntp2.hetzner.de)

peer offset 2a01:4f8:0:a112::2:2 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 2a01:4f8:0:a112::2:2 (ntp2.hetzner.de) -1.160 -1.160 -1.056 0.077 0.622 0.709 0.709 1.678 1.868 0.503 0.024 ms -4.322 11.02

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Jitters

peer jitters plot

The RMS Jitter of all refclocks and servers. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 131.188.3.221

peer jitter 131.188.3.221 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 131.188.3.221 30.869 30.869 54.404 235.821 588.060 614.394 614.394 533.656 583.525 156.964 270.079 µs 3.07 7.238

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 185.131.196.23

peer jitter 185.131.196.23 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 185.131.196.23 32.209 32.209 54.271 248.731 829.714 978.243 978.243 775.443 946.034 216.536 304.943 µs 2.61 7.502

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 192.171.1.150

peer jitter 192.171.1.150 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 192.171.1.150 0.035 0.035 0.064 0.394 6.120 10.527 10.527 6.056 10.492 2.034 1.301 ms 1.382 6.73

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 193.79.237.14

peer jitter 193.79.237.14 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 193.79.237.14 0.043 0.043 0.060 0.247 1.029 1.088 1.088 0.970 1.045 0.265 0.331 ms 2.206 6.281

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 2001:628:2030:dcf1::ac0 (ts1.aco.net)

peer jitter 2001:628:2030:dcf1::ac0 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 2001:628:2030:dcf1::ac0 (ts1.aco.net) 0.633 0.633 0.677 1.525 3.111 3.650 3.650 2.434 3.017 0.776 1.733 ms 6.214 16.87

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 2001:638:a000:1123:123::1 (ntp0.rrze.ipv6.uni-erlangen.de)

peer jitter 2001:638:a000:1123:123::1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 2001:638:a000:1123:123::1 (ntp0.rrze.ipv6.uni-erlangen.de) 34.450 34.450 53.211 226.682 578.428 671.448 671.448 525.217 636.998 165.374 274.082 µs 2.85 6.588

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 2a01:4f8:0:a112::2:2 (ntp2.hetzner.de)

peer jitter 2a01:4f8:0:a112::2:2 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 2a01:4f8:0:a112::2:2 (ntp2.hetzner.de) 44.484 44.484 56.455 219.207 572.145 665.053 665.053 515.690 620.569 165.751 264.434 µs 2.618 6.051

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Summary


Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Frequency Offset -6.775 -6.775 -6.745 -6.432 -6.185 -6.169 -6.169 0.560 0.606 0.156 -6.426 ppm -7.561e+04 3.201e+06
Local Clock Time Offset -1.125 -1.125 -0.964 -0.071 0.662 0.805 0.805 1.626 1.930 0.516 -0.053 ms -4.887 11.82
Local RMS Frequency Jitter 14.686 14.686 17.829 36.825 51.337 61.844 61.844 33.508 47.158 10.538 36.103 ppb 21.51 72.04
Local RMS Time Jitter 132.474 132.474 146.307 180.499 256.654 275.179 275.179 110.347 142.705 32.664 190.077 µs 127.1 696.4
Server Jitter 131.188.3.221 30.869 30.869 54.404 235.821 588.060 614.394 614.394 533.656 583.525 156.964 270.079 µs 3.07 7.238
Server Jitter 185.131.196.23 32.209 32.209 54.271 248.731 829.714 978.243 978.243 775.443 946.034 216.536 304.943 µs 2.61 7.502
Server Jitter 192.171.1.150 0.035 0.035 0.064 0.394 6.120 10.527 10.527 6.056 10.492 2.034 1.301 ms 1.382 6.73
Server Jitter 193.79.237.14 0.043 0.043 0.060 0.247 1.029 1.088 1.088 0.970 1.045 0.265 0.331 ms 2.206 6.281
Server Jitter 2001:628:2030:dcf1::ac0 (ts1.aco.net) 0.633 0.633 0.677 1.525 3.111 3.650 3.650 2.434 3.017 0.776 1.733 ms 6.214 16.87
Server Jitter 2001:638:a000:1123:123::1 (ntp0.rrze.ipv6.uni-erlangen.de) 34.450 34.450 53.211 226.682 578.428 671.448 671.448 525.217 636.998 165.374 274.082 µs 2.85 6.588
Server Jitter 2a01:4f8:0:a112::2:2 (ntp2.hetzner.de) 44.484 44.484 56.455 219.207 572.145 665.053 665.053 515.690 620.569 165.751 264.434 µs 2.618 6.051
Server Offset 131.188.3.221 -1.130 -1.130 -0.969 -0.035 0.651 0.720 0.720 1.620 1.850 0.492 -0.033 ms -4.663 11.26
Server Offset 185.131.196.23 -1.032 -1.032 -0.896 0.091 0.727 0.848 0.848 1.624 1.880 0.489 0.086 ms -3.461 8.142
Server Offset 192.171.1.150 -10.615 -10.615 -0.881 0.171 0.807 0.853 0.853 1.688 11.468 1.480 -0.063 ms -10.47 78.14
Server Offset 193.79.237.14 -1.580 -1.580 -1.447 -0.452 0.183 0.244 0.244 1.630 1.824 0.475 -0.462 ms -13.95 43.49
Server Offset 2001:628:2030:dcf1::ac0 (ts1.aco.net) -0.673 -0.673 -0.355 0.779 2.141 5.642 5.642 2.496 6.315 0.981 0.873 ms 2.069 11.38
Server Offset 2001:638:a000:1123:123::1 (ntp0.rrze.ipv6.uni-erlangen.de) -1.223 -1.223 -1.051 -0.082 0.577 0.612 0.612 1.629 1.835 0.491 -0.071 ms -5.398 13.99
Server Offset 2a01:4f8:0:a112::2:2 (ntp2.hetzner.de) -1.160 -1.160 -1.056 0.077 0.622 0.709 0.709 1.678 1.868 0.503 0.024 ms -4.322 11.02
Summary as CSV file


Glossary:

frequency offset:
The difference between the ntpd calculated frequency and the local system clock frequency (usually in parts per million, ppm)
jitter, dispersion:
The short term change in a value. NTP measures Local Time Jitter, Refclock Jitter, and Server Jitter in seconds. Local Frequency Jitter is in ppm or ppb.
kurtosis, Kurt:
The kurtosis of a random variable X is the fourth standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of kurtosis. A normal distribution has a kurtosis of three. NIST describes a kurtosis over three as "heavy tailed" and one under three as "light tailed".
ms, millisecond:
One thousandth of a second = 0.001 seconds, 1e-3 seconds
mu, mean:
The arithmetic mean: the sum of all the values divided by the number of values. The formula for mu is: "mu = (∑xi) / N". Where xi denotes the data points and N is the number of data points.
ns, nanosecond:
One billionth of a second, also one thousandth of a microsecond, 0.000000001 seconds and 1e-9 seconds.
percentile:
The value below which a given percentage of values fall.
ppb, parts per billion:
Ratio between two values. These following are all the same: 1 ppb, one in one billion, 1/1,000,000,000, 0.000,000,001, 1e-9 and 0.000,000,1%
ppm, parts per million:
Ratio between two values. These following are all the same: 1 ppm, one in one million, 1/1,000,000, 0.000,001, and 0.000,1%
‰, parts per thousand:
Ratio between two values. These following are all the same: 1 ‰. one in one thousand, 1/1,000, 0.001, and 0.1%
refclock:
Reference clock, a local GPS module or other local source of time.
remote clock:
Any clock reached over the network, LAN or WAN. Also called a peer or server.
time offset:
The difference between the ntpd calculated time and the local system clock's time. Also called phase offset.
σ, sigma:
Sigma denotes the standard deviation (SD) and is centered on the arithmetic mean of the data set. The SD is simply the square root of the variance of the data set. Two sigma is simply twice the standard deviation. Three sigma is three times sigma. Smaller is better.
The formula for sigma is: "σ = √[ ∑(xi-mu)^2 / N ]". Where xi denotes the data points and N is the number of data points.
skewness, Skew:
The skewness of a random variable X is the third standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of skewness. Wikipedia describes it best: "The qualitative interpretation of the skew is complicated and unintuitive."
A normal distribution has a skewness of zero.
upstream clock:
Any server or reference clock used as a source of time.
µs, us, microsecond:
One millionth of a second, also one thousandth of a millisecond, 0.000,001 seconds, and 1e-6 seconds.



This page autogenerated by ntpviz, part of the NTPsec project
html 5    Valid CSS!
